- Kamera
- Sensorius1/1.8″ Progressive Scan CMOS
- Maks. rezoliucija1920 × 1080
- Min. apšvietimasColor: 0.0005Lux @ (F1.2, AGC ON), B/W:0.0001Lux @ (F1.2, AGC ON), 0 lux with light
- Užrakto greitis1/1 s to 1/30000 s
- Lėtas užraktasYes
- Diena & Naktis IR cut filter
- Priartinimas20 × optical, 16 × digital
- Lęšis
- Židinio nuotolis6.7 mm to 134 mm
- Priartinimo greitisApprox. 7 s
- FOV
Horizontal field of view: 53° to 4.9° (wide-tele),
Vertical field of view: 31.3° to 2.7° (wide-tele),
Diagonal field of view: 59.6° to 5.6° (wide-tele)
- DiafragamaMax. F1.2
- FokusavimasAuto, semi-auto, manual
- Apšvietimas
- Papildomo apšvietimo diapazonas
White light: up to 100 m
IR: up to 150 m
- Papildomo apšviešimo tipasHybrid(IR and White Light)
- PTZ
- Judėjimo kampas (Pan)360°
- Judėjimo kampas (Tilt)-15° to 90° (auto flip)
- Pan greitisPan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
- Tilt greitisTilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
- Proporcingas PanYes
- Iš anksto išsaugoti nustatymai300
- Patruliavimas8 patrols, up to 32 presets for each patrol
- Išsaugotų rėžimų skenavimas4 pattern scans
- Išjungimo atmintisYes
- Park ActionPreset, patrol scan, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
- 3D pozicijaYes
- PTZ būsenos vaizdavimasYes
- Išsaugotų nustatymų sustabdymasYes
- Užduočių grafikasPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux išvestis
- Vaizdas
- Pagrindinis srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Antrinis srautas
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 24 fps (704 × 480, 640 × 480, 352 × 240)
- Trečias srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Vaizdo suspaudimas
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
- Vaizdo bitų greitis32 kbps to 16384 kbps
- H.264 tipasBaseline Profile/Main Profile/High Profile
- H.265 tipasMain Profile
- SVCH.264 and H.265 encoding
- ROI8 fixed regions for each stream
- Garsas
- Garso suspaudimasG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC-LC
- Garso bitų greitis64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Garso atrankos dažnis8 kHz/16 kHz/32 kHz/48 kHz
- Pašalinių garsų šalinimasYes
- Internetas
- Vidinė atmintisNAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- ProtokolaiIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets
- APIOpen Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- Tiesioginis vaizdo žiūrėjimasUp to 20 channels
- User/HostUp to 32 users, 3 user levels: administrator, operator, and user
- SaugumasPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
- KlientasiVMS-4200, HikCentral Pro, Hik-Connect
- NaršyklėIE11, Chrome 57+, Firefox 52+, Safari 11+
- Nuotrauka
- Diena/Naktis režimasDay, Night, Auto, Schedule
- Nuotraukų pagražinimasBLC, HLC, 3D DNR
- WDR120 dB
- Rūko šalinimasDigital defog
- Vaizdo stabilizavimasEIS
- Regioninė ekspozicijaYes
- Regioninis fokusavimasYes
- Nuotraukos nustatymaiSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Privatumo kaukė24 programmable polygon privacy masks, mask color or mosaic configurable
- SNR> 52 dB
- Sąsaja
- Interneto sąsaja1 RJ45 10M/100M self-adaptive Ethernet port
- Saugyklos vietaBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Signalizacija2 inputs, 1 išvestis
- Garsas1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- PerkrovimasYes
- Įmontuotas garsiakalbis1 built-in speaker with effective distance reaching max. 30 meters
- Funkcijos
- Pagrindinės funkcijosMotion detection, video tampering alarm, exception, alarm input and išvestis
- Išmaniosios funkcijosLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
- Išmanus sekimasManual tracking, auto-tracking
- Signalizacijos sąsajaUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
- Išmaniosios funkcijos
- Veido atpažinimas
Detects up to 5 faces simultaneously.
Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
- Perimetro apsauga
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
- Pagrindinis
- Sistemos parametrai
24 VAC, max. 42 W (including max. 12 W for IR and max. 2 W for heater);
Hi-PoE
- Darbo sąlygos-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
- Rasos šalinimasYes
- MedžiagaADC12
- DydisØ 220 mm × 357.3 mm (Ø8.66″ × 14.07″)
- Approx. 5.5 kg (12.13 lb.)
- Patvirtinimai
- ApsaugaIP66 (IEC 60529-2013), IK10 (excluding glass window), TVS 6000V lightning protection, surge protection and voltage transient protection
- EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2019);
KC (KN 32: 2015, KN 35: 2015)
- Saugumas
UL (UL 62368-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 62368-1:2014+A11:2017);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (SANS IEC60950-1)
- Aplinkosauga
CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
