NVR4108HS-8P-4KS2, Įrašymo įrenginys 8CH, 1HDD, 8MP
367,84 Į krepšelį

NVR4108HS-8P-4KS2, Įrašymo įrenginys 8CH, 1HDD, 8MP

367,84

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Main Processor: Quad-core embedded processor
Operating System: Embedded LINUX
Audio and Video
IP Camera Input: 8/16 Channel
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Display Interface:1 HDMI, 1 VGA
Resolution
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity: 2ch@4K(30fps)/8ch@1080P(30fps)
OSD: Camera title, Time, Camera lock, Motion detection, Recording
Compression: Smart H.265+/H.265/Smart H.264+/H.264
Resolution: 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
Record Rate: 80Mbps
Bit Rate: 16Kbps ~ 20Mbps Per Channel
Record Mode
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
Trigger Events
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input: N/A
Alarm output: N/A
Backup Mode: USB Device/Network
Interface: 1 RJ-45 Port (10/100Mbps)
Ethernet Port: 1 Independent 100Mbps Ethernet Port
PoE: 8 Ports(IEEE802.3at/af)
Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, SNMP, IP Search (Support IP camera, DVR, NVS, etc.)
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability: ONVIF 2.4, SDK, CGI
Internal HDD: 1 SATA III Port, Up to 6 TB capacity for each HDD
HDD Mode: Single
USB: 2 ports(1 Rear USB2.0, 1 Front USB2.0)
RS232: N/A
RS485: N/A
Power Supply: DC48V/2A
NVR: <8.3W (Without HDD)
PoE: Max 25.5w for single port, 80w in total
Operating Conditions: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Dimensions: Compact 1U, 260mm×224.9mm×47.6mm
Net Weight: 0.8kg (1.76 lb) (without HDD)
Gross Weight: 1.6kg(3.53 lb)(without HDD)
DAHUA

Papildoma informacija

Gamintojas

Kanalų skaičius

PoE

Diskų skaičius
