IPC HFW5442E-ZE-2712 IP vaizdo kamera 4MP, 2.7-12mm, IR50

IPC HFW5442E-ZE-2712 IP vaizdo kamera 4MP, 2.7-12mm, IR50

486

Liko 4 (galime užsakyti)

Sandėlyje liko tik: 4 vnt.

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Image Sensor: 1/1.8” 4Megapixel progressive scan CMOS
Effective Pixels: 2688(H) x 1520(V)
RAM/ROM: 1GB/128MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.0024Lux/F1.8 ( Color,1/3s,30IRE)0.059Lux/F1.8 ( Color,1/30s,30IRE)0Lux/F1.8 (IR on)
IR Distance: Distance up to 50m (164ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 4
Lens Type: Motorized
Mount Type: Board-in
Focal Length: 2.7mm~12mm
Max. Aperture: F1.8
Angle of View: H: 114°~47°, V:62°~26°
Optical Zoom: 4.4x
Aperture Type: Auto
Close Focus Distance: 1.2m(3.94ft)
DORI Distance: Lens: Detect,Observe,Recognize,Identify W: 56m(184ft),20m(66ft),9m(30ft),4m(13ft) T: 125m(410ft),50m(164ft),22m(72ft),11m(36ft)
Pan/Tilt/Rotation Range: Pan:0 °~360 °, Tilt:0 °~90 °, Rotation:0 °~360 °
Face Capture: Support face image capture
Face Attributes: Support 6 kinds of face attributes extraction: Age, Gender,Expression(Jolly/Surprise/Normal/Rage/Sad/Disgusted/Confused/Frightened), Glasses,Mouth Mask, Moustache & Beard
Perimeter Protection: Tripwire, Intrusion(Human & Vehicle classification)
People Counting: Line crossing people counting, Region people counting
Event Trigger: Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly
General Intelligence: Object Abandoned/Missing
Compression: H.265+/H.265/H.264+/H.264/H.264B/H.264H/MJPEG(sub stream)
Streaming Capability: 3 Streams
Resolution: 2688×1520/2304×1296/1080P(1920×1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)
Frame Rate: Main Stream: 2688×1520(1~25/30fps),Sub Stream: D1(1~25/30fps),Third Stream: 1080P(1~11fps)
Bit Rate Control: CBR/VBR
Bit Rate: H.264: 32~ 8192KbpsH.265: 19~ 8192Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS): Support
Smart IR: Support
Defog: Support
Digital Zoom: N/A
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)
Compression: G.711a/ G.711Mu/ AAC/ G.726/G.723
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP,SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP,QoS, UPnP,NTP
Interoperability: ONVIF(Profile S/Profile G), CGI,Milstone,Genetec,P2P
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users
Edge Storage: NASFTPMirco SD card 256GB
Web Viewer: IE(versions newer than IE8), Chrome, Firefox, Safari(versions newer than Safari 12)
Management Software: Smart PSS, DSS, P2P
Smart Phone: iOS, Android
Certifications: CE-LVD:EN60950-1CE-EMC:Electromagnetic Compatibility Directive 2014/30/EUFCC:47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Video Interface: N/A
Audio Interface: 1/1 channel In/Out
Alarm: 2 channel In: 5mA 5VDC1 channel Out: 300mA 12VDC
Power Supply: DC12V(±30%), PoE(802.3af)(Class 0)
Power Consumption: DC12V:3W 9.9W(IR on)PoE:3.7W 10.9W(IR on)
Operating Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / 10%RH~95% RH
Strorage Conditions: +5° C ~ +40° C (+41° F ~ +104° F) (daily temperature difference within 15° C/59° F ) / 10%RH~95% RH
Ingress Protection: IP67
Vandal Resistance: IK10
Casing: Metal,plastic
Dimensions: 273.2mm×95.0mm×95.0mm (10.76”×3.74”×3.74”)
Net Weight: 1.11Kg (2.44lb)
Gross Weight: 1.51Kg (3.33lb)
