IPC HFW2431T-ZS-27135, IP vaizdo kamera 4MP, 2.7-12mm, IR50
315,81 Į krepšelį

IPC HFW2431T-ZS-27135, IP vaizdo kamera 4MP, 2.7-12mm, IR50

315,81

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

„Image Sensor: 1/3” 4Megapixel progressive CMOS
Effective Pixels: 2688(H) x1520(V)
RAM/ROM: 512MB/32MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination: 0.03Lux/F1.4(Color,1/3s,30IRE) 0.3Lux/F1.4(Color,1/30s,30IRE) 0Lux/F1.4(IR on)
S/N Ratio: More than 45dB
IR Distance: Distance up to 60m(197ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 4
Lens Type: Motorized(-ZS),Manual(-VFS)
Mount Type: Board-in
Focal Length: 2.7mm~13.5mm
Max. Aperture: F1.4
Angle of View: H – 104°~28°, V – 55°~16°
Focus Control: Motorized(-ZS),Manual(-VFS)
Close Focus Distance: 0.2m
Pan/Tilt Range: Pan – 0° ~355°, Tilt – 0° ~90°, Rotation – 0° ~330°
Compression: H.265+/H.265/H.264+/H.264
Streaming Capability: 2 Streams
Resolution: (2688×1520) / (2560×1440) / (2304×1296) / 1080P(1920×1080) / SXGA(1280×1024) / 1.3M(1280× 960) / 720P(1280×720) / D1(704×576/704×480) / VGA(640×480)CIF(352×288/352×240)
Frame Rate: 4M (1 ~ 20fps)/3M(1 ~ 25/30fps), D1/CIF(1 ~ 25/30fps)
Bit Rate Control: CBR/VBR
Bit Rate: H.265 – 12K ~ 8448Kbps, H.264 – 32K ~ 10240Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Smart IR: Support
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP ,DNS,DDNS,PPPOE,IPv4/v6,SNMP,QoS,UPnP,NTP
Interoperability: ONVIF, PSIA, CGI
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users
Edge Storage: NAS Local PC for instant recording Micro SD Card 128GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS,DMSS
Smart Phone: IOS, Android
Certifications: CE (EN 60950:2000), UL – UL60950-1, FCC – FCC Part 15 Subpart B
Power Supply: DC12V PoE (802.3af)(Class 0)
Power Consumption: <11.74W(-ZS), <9.09W(-VFS)
Operating Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection: IP67
Casing: Metal
Dimensions: 72mm×80mm×212.8mm ((2.8″” x 3.1″”x 8.4″”))
Net Weight: 0.685Kg (1.51lb)
Gross Weight: 0.86Kg (1.90lb)”
DAHUA

Papildoma informacija

Gamintojas

Korpuso tipas

Raiška

Objektyvo tipas
