DH-PTZ83240-HNF-WA, IP kamera, greitaeigė
4.145,46 Į krepšelį

DH-PTZ83240-HNF-WA, IP kamera, greitaeigė


Išankstinis užsakymas


Image Sensor: 1/1.8″ CMOS
Max. Resolution: 2MP
Effective Pixels: 1920(H)×1080 (V)
Electronic Shutter Speed: 1/1–1/30000s
Scanning Mode: Progressive Scanning
Minimum Illumination:
Color: 0.001Lux@F1.4
B/W: 0.0001Lux@F1.4
0Lux (IR light on)
IR Distance: 400m( 1312.34ft )
IR On/Off: Control Zoom Prio/Manual/SmartIR
IR LED Number: 10
Wiper: Support
Focal Length: 5.6 mm–223 mm
Aperture F1.4–F4.5
Field of View H: 1.8°~70.3°; V: 1.2°–35°; D: 2.4°–66.9°
Optical Zoom: 40x
Focus Control: Auto/Semi-Auto/Manual
Close Focus Distance: 0.5 m–2 m
Iris Control: Auto
Pan/Tilt Range Pan: 0°–360°; Tilt: -90°~45°
Manual Control Speed Pan: 0.1°–160°/s; Tilt: 0.1°–60°/s
Preset Speed Pan: 160°/s; Tilt: 60°/s
Presets 300
Tour 8(up to 32 preset per tour)
Pattern Number 5
Scanning Number 5
Speed Adjustment Support
Power-off Memory Support
Idle Motion Preset/Tour/Pattern/Scanning
Protocol DH-SD
Pelco-P/D(Auto recognition)
Perimeter Protection
Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.
Auto Tracking: Support
Face Recognition: Support
Event Trigger: Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly.
General IVS: Object Abandoned/Missing
Video Compression H.265, H.264Main/High/Baseline Profile, MJPEG(Sub Stream)
Streaming Capability 3 Streams
Resolution 1080P (1920×1080); 1.3M(1280×960); 720P(1280×720); D1 (704× 576); CIF (352×288)
Frame Rate
Main stream:1080P/1.3M/720P(1–25/30fps)
Sub stream 1: D1/CIF(1–25/30fps)
Sub stream 2: 1080P/1.3M/720P(1–25/30fps), D1/CIF(1–25/30fps)
Bit Rate Control Variable Bit Rate/Constant Bit Rate
Bit Rate H.264: 1792 Kbps–9216 Kbps
H.265: 512 Kbps–5632 Kbps
Day/Night: Support
BLC: Support
WDR: 120dB
HLC: Support
White Balance: Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/
Natural/Street: lamp
Gain Control: Auto/Manual
Noise Reduction: 2D/3D
Motion Detection: Support
Region of Interest (RoI): Support
Electronic Image: Stabilization
(EIS) Support
Defog support
Digital Zoom 16x
Flip: 180°
Privacy Masking: Up to 24 areas
Audio Compression G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2
Ethernet: 1 RJ-45 Port 10/100Base-T
Audio In :1
Audio: Out 1
Alarm: 7 in and 2 out
Analog Output: 1 BNC
RS-485: 1
Protocol: IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE
Interoperability ONVIF Profile S&G; CGI
Streaming Method Unicast/Multicast
Max. User Access 20 (Total bandwidth 64M)
Edge Storage FTP; Micro SD card (256G)
Management Software: Smart Player, Smart PSS, DSS, Easy4ip
Power Supply AC24V/8.35A±25%
Power Consumption 39W
70W (IR light on, PTZ, wiper, heater)
Operating Conditions -40°C ~ 70°C (–40°F to +158°F)
Operating Humidity ?95%RH
Ingress Protection IP67; TVS 6000V lightning protection; surge protection
Dimensions 210.7mm×366.5mm×498.7mm
Weight Net Weight: 14 kg (30.86 lb); Gross Weight: 19.77 kg
