DAHUA XVR5104C-X1, ĮRAŠYMO ĮRENGINYS 4CH, 1HDD, 5MP

Main Processor: Embedded Processor

Operating System: Embedded LINUX

Analog Camera Input: 4 Channel, BNC

HDCVI Camera: 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps

AHD Camera: 5MP, 4MP, 1080P@25/30, 720P@25/30fps

TVI Camera: 5MP, 4MP, 1080P@25/30, 720P@25/30fps

CVBS Camera: PAL/NTSC

IP Camera Input: 4+2 Channel, each channel up to 6MP

Audio In/Out: 1/1, RCA

Two-way Talk: Reuse audio in/out, RCA

Compression: H.265+/H.265/H.264+/H.264

Resolution: 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF

Main stream: the 1st channel 5M-N(1~10fps), other channels 4M-N/1080P(1~15fps), 1080N/720P/960H/D1/CIF (1~25/30fps)

Sub stream: D1/CIF(1~15fps)

Audio Compression: AAC(only for the 1st channel), G.711A, G.711U, PCM

Audio Sample Rate: 8KHz, 16 bit Per Channel

Interface: 1 HDMI ,1 VGA

Resolution: 1920×1080, 1280×1024, 1280×720

When IP extension mode not enabled: 1/4

When IP extension mode enabled: 1/4/6

Network Interface: 1 RJ-45 Port (100M)

Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)

Interoperability: ONVIF 16.12, CGI Conformant

Internal HDD: 1 SATA Port, up to 6TB capacity

USB: 2 USB 2.0

Power Supply: DC12V/1.5A

Power Consumption: (without HDD) <10W

Dimensions: Smart 1U, 205mm×211mm×45mm (8.1“×8.3”×1.8“)

Operating Conditions: -10°C ~ +45°C (+14°F ~ +113°F), up to 55°C/131°F with case fan, 10~ 90% RH

FCC: Part 15 Subpart B

CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
