DAHUA NVR4104-P-4KS2, ĮRAŠYMO ĮRENGINYS 4CH, 1HDD, 8MP, 4POE

DAHUA NVR4104-P-4KS2, ĮRAŠYMO ĮRENGINYS 4CH, 1HDD, 8MP, 4POE

322

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Main Processor: Quad-core embedded processor

Operating System: Embedded LINUX

Interface: 1 HDMI, 1 VGA

Resolution: 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768

Multi-screen Display: 4CH – 1/4, 8CH – 1/4/8/9,

OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Trigger Events: Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Video Detection: Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering

Playback: 4CH – 1/4, 8CH – 1/4/8

Search Mode: Time /Date, MD and Exact Search (accurate to second), Smart search

Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Backup Mode: USB Device/Network

Internal HDD: 1 SATA III Port, Up to 6 TB capacity for each HDD

HDD Mode: Single

USB: 2 USB Ports (2 USB2.0)

Third-party Support: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more

IP Camera Input: 4/8 Channel

Two-way Talk: 1 Channel Input, 1 Channel Output, RCA

Compression: H.265/H.264

Resolution: 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.

Record Rate: 80Mbps

Bit Rate: 16Kbps ~ 20Mbps Per Channel

Record Mode: Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop

Record Interval: 1 ~ 120 min (default – 60 min), Pre-record – 1 ~ 30 sec, Post-record – 10 ~ 300 sec

Interface: 1 RJ-45 Port (10/100Mbps)

Ethernet Port: 1 Independent 100Mbps Ethernet Port

PoE: 4 ports (IEEE802.3at/af)(4Mbps is recommended per channel)

Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip

Max. User Access: 128 users

Smart Phone: iPhone, iPad, Android

Interoperability: ONVIF 2.4, CGI Conformant

Power Supply: DC48V/1.5A

Power Consumption: NVR – <7.5W (Without HDD), PoE – Max 25.5w for single port, 50w in total

Operating Conditions: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH

Dimensions: Smart 1U, 204.6mm×204.6mm×45.6mm (8.1"" x 8.1"" x 1.8"")

Net Weight: 0.45kg (0.99 lb) (without HDD)

Gross Weight: 1.5kg(3.31 lb)(without HDD)

CE: EN55032, EN55024, EN50130-4, EN60950-1

FCC: Part 15 Subpart B, ANSI C63.4-2014

UL: UL60950-1+CAN/CSA C22.2 No.60950-1

DAHUA
