DAHUA IPC HFW8241E-Z-27135, IP VAIZDO KAMERA 2MP, 2.7-13.5MM, IR50

DAHUA IPC HFW8241E-Z-27135, IP VAIZDO KAMERA 2MP, 2.7-13.5MM, IR50

346

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Image Sensor: 1/2.8” 2Megapixel progressive scan CMOS

Effective Pixels: 1920(H)x1080(V)

RAM/ROM: 1024MB/4096MB

Scanning System: Progressive

Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s

Minimum Illumination: 0.005Lux/F1.6 (Color,1/3s,30IRE), 0.05Lux/F1.6 (Color,1/30s,30IRE), 0Lux/F1.6 (IR on)

S/N Ratio: Less than 50dB

IR Distance: Distance up to 50m(164ft)

IR On/Off Control: Auto/Manual

IR LEDs: 4

Lens Type: Motorized

Mount Type: Board-in

Focal Length: 2.7~13.5mm motorized

Max. Aperture: F1.6

Angle of View: H – 107.17° (31.82°), V – 56.47° (17.62°)

Optical Zoom: 5x

Focus Control: Motorized

Close Focus Distance: 0.3m(0.98ft)

Pan/Tilt/Rotation Range: Pan – 0?~360?, Tilt – 0?~90?, Rotation – 0?~360?

People Counting: Line crossing people counting, Region people counting, Height filter, Loitering filter

Event Trigger: Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal, Access,Storage anomaly

General Intelligence: Tripwire, Intrusion, Object Abandoned/Missing

Compression: H.265/H.264/H.264B/H.264H/MJPEG(sub stream)

Smart Codec: Support H.265+/H.264+

Streaming Capability: 3 Streams

Resolution: 1080P(1920×1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)

Frame Rate: Main Stream – 1080P(1~50/60fps), Sub Stream – D1 (1 ~ 50/60fps), Third Stream – 1080P(1~50/60fps)

Bit Rate Control: CBR/VBR

Bit Rate: H.264 – 24~10240Kbps, H.265 – 14~6144Kbps

Day/Night: Auto(ICR) / Color / B/W

BLC Mode: BLC / HLC / WDR(140dB)/ SSA

White Balance: Auto/Manual

Gain Control: Auto/Manual

Noise Reduction: 3D DNR

Motion Detection: Off / On (4 Zone, Rectangle)

Region of Interest: Off / On (4 Zone)

Electronic Image Stabilization (EIS): Support

Smart IR: Support

Defog: Support

Digital Zoom: 16x

Flip: 0°/90°/180°/270°

Mirror: Off / On

Privacy Masking: Off / On (4 Area, Rectangle)

Compression: G.711a/ G.711Mu/ AAC/ G.726

Ethernet: RJ-45 (100/1000Base-T)

Protocol: HTTP,HTTPs,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPOE,IPv4/v6,QoS,UPnP,NTP,Bonjour,IEEE 802.1x,Multicast,ICMP,IGMP,SNMP,TLS

Interoperability: ONVIF Profile S&G, API

Streaming Method: Unicast / Multicast

Max. User Access: 10 Users/20 Users

Edge Storage: NAS, Local PC for instant recording, Micro SD card 128GB

Web Viewer: IE, Chrome, Firefox, Safari

Management Software: Smart PSS, DSS, DMSS

Smart Phone: IOS, Android

Certifications: CE (EN 60950:2000), UL – UL60950-1, FCC – FCC Part 15 Subpart B

Video Interface: 1 Port(For adjustment only)

Audio Interface: 1/1 channel In/Out

RS485: 1 port

Alarm: 2 channel In: 5mA 5VDC, 1 channel Out: 1A 30VDC / 0.5A 50VAC

Power Supply: DC12V, AC24V, PoE(802.3af)(Class 0)

Power Consumption: DC12V – 4.4W 14.7W(IR on), PoE – 4.4W 14.3W(IR on)

Operating Conditions: -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Storage Conditions: -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection, IP67

Vandal Resistance: IK10

Casing: Metal

Dimensions: ?159.1mm*117.9mm

Net Weight: 1.06Kg (2.34lb)

Gross Weight: 1.28Kg (2.82lb)

DAHUA
