DAHUA IPC HFW5541T-ASE-0280B, IP VAIZDO KAMERA 5MP, 2.8MM, IR80

DAHUA IPC HFW5541T-ASE-0280B, IP VAIZDO KAMERA 5MP, 2.8MM, IR80

323

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Image Sensor: 1/2.7” 5Megapixel progressive scan CMOS

Max. Resolution: 2592 (H) × 1944 (V)

RAM/ROM: 512 MB/128 MB

Electronic Shutter Speed: Auto/Manual, 1/3 s–1/100000 s

S/N Ratio: > 56 dB

Minimum Illumination: 0.005 Lux@F1.6

Illumination Distance: Distance up to 80 m (262 ft)

Illuminator On/Off Control: Auto/Manual

Illuminator Number: 4(IR LED)

Lens Type: Fixed-focal

Mount Type: Board-in

Focal Length: 2.8 mm, 3.6 mm, 6.0 mm, 8.0 mm, 12.0 mm

Max. Aperture: F1.6 (2.8 mm–8.0 mm), F2.0 (12.0 mm)

Angle of View: H: 102°, V: 71°/H: 84°, V: 58°/H: 51°, V: 37°/ H: 38°, V:28°/H: 25°, V:18°

Aperture Type: Fixed

Close Focus Distance: 0.9 m (2.95 ft)/1.6 m (5.25 ft)/3.1 m (10.17 ft)/4.5 m (14.73 ft)/10.3 m (33.79 ft)

Pan/Tilt/Rotation Range: Pan: 0?–360?; Tilt: 0?–90?; Rotation: 0?–360?

Face Detection

Face detection; track; optimization; snapshot; face enhancement; face exposure; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting

Perimeter Protection

Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection

People Counting: Support the counting of enter number, leave number, and pass number, and displaying and outputting yearly/monthly/daily reports.

Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.

Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm

General Intelligence

Event Trigger: Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly

General Intelligence: Object Abandoned/Missing

Heat Map: Yes

Video Compression:

H.265,H.264,H.264B,H.264H,

MJPEG (only supported by sub stream)

Smart Codec

Smart H.265+/ Smart H.264+

Streaming Capability: 3 Streams

Resolution: 2592 × 1944/2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240)

Frame Rate

Main Stream: 2592 × 1944 (1 fps–20 fps)

2560 × 1440 (1 fps–25/30 fps)

1920 × 1080 (1 fps–50/60 fps)

Sub Stream: D1 (1 fps–20/30 fps)

D1 (1 fps–50 fps)

Third Stream: 1080P (1 fps–17 fps)

Bit Rate Control: CBR/VBR

Bit Rate

H.264: 32 Kbps–8192 Kbps

H.265: 19 Kbps–8192 Kbps

Day/Night: Auto(ICR)/Color/B/W

BLC Mode: BLC/HLC/WDR (120 dB)

White Balance: Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control: Auto/Manual

Noise Reduction: 3D DNR

Motion Detection: Off/On (4 Zone, Rectangle)

Region of Interest: Off/On (4 Zone)

Smart Illumination: Yes

Defog: Yes

Flip: 0°/90°/180°/270°

Mirror: Off/On

Privacy Masking: Off/On (4 Area, Rectangle)

Audio Compression: G.711a, G.711Mu, G.726, AAC, G.723

Alarm Event: No SD card;SD card full;SD card error;network disconnection;IP conflict;illegal access;motion detection;video tampering;Defocus Detection;scene changing;intrusion;tripwire;abandoned object;missing object;fast moving;parking detection;loitering detection;people gathering;audio detection;people counting;face detection;People counting in area;Stay alarm;People No. exception detection;Queue Management

Network: RJ-45 (10/100 Base-T)

SDK and API: Yes

Protocol: IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP

Interoperability: ONVIF (Profile S/Profile G/Profile T), CGI, Milstone, Genetec, P2P

User/Host: 20 Users

Storage: NAS;FTP;SFTP;Dahua Cloud Micro SD card 256 GB

Browser: IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12)

Management Software: Smart PSS, DSS, DMSS

Mobile Phone: iOS, Android

Certifications

CE-LVD: EN62368-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Audio Interface: 1/1 channel In/Out

Alarm

1 channel In: 5mA 5V DC

1 channel Out: 300mA 12V DC

Power Supply: DC 12V (±30%), PoE (802.3af)

Power Consumption: <9.5W

Operating Conditions: -40°C to +60°C (-40°F to +140°F)/Less than 95% RH

Storage Conditions: -40°C to +60°C (-40°F to +140°F)

Protection Grade: IP67,IK10

Dimensions: 244.1 mm × 79.0 mm × 75.9 mm (9.61” × 3.11” × 2.99”)

Net Weight: 0.815 kg (1.80 lb)

Gross Weight: 1.08 kg (2.38 lb)

DAHUA
