DAHUA IPC HFW2531TP-ZAS, 5MP WDR IR „BULLET“ TINKLO KAMERA

DAHUA IPC HFW2531TP-ZAS, 5MP WDR IR „BULLET“ TINKLO KAMERA

350

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Image Sensor: 1/2.7” 5Megapixel progressive CMOS

Effective Pixels: 2592(H) x1944(V)

RAM/ROM: 512MB/32MB

Scanning System: Progressive

Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s

Minimum Illumination: 0.02Lux/F1.6( Color,1/3s,30IRE), 0.2Lux/F1.6( Color,1/30s,30IRE), 0Lux/F1.6(IR on)

S/N Ratio: More than 50dB

IR Distance: Distance up to 60m(197ft)

IR On/Off Control: Auto/ Manual

IR LEDs: 4

Lens Type: Motorized(-ZS),Manual(-VFS)

Mount Type: Board-in

Focal Length: 2.7mm~13.5mm

Max. Aperture: F1.4

Angle of View: H – 95°~27°, V – 70°~20°

Focus Control: Motorized(-ZS), Manual(-VFS)

Close Focus Distance: 0.3m

Pan/Tilt Range: Pan – 0° ~360°, Tilt – 0° ~90°, Rotation – 0° ~360°

Event Trigger: Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly

IVS: Tripwire, Intrusion

Compression: H.265/H.264H/MJPEG(Sub Stream)

Smart Codec: Support H.265+/H.264+

Streaming Capability: 2 Streams

Resolution: 5M(2592×1944)/4M(2688×1520)/3M(2304×1296/2048×1536)/1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)

Frame Rate: Main Stream – 5M (1 ~ 15fps)/3M(1 ~ 25/30fps), Sub Stream – D1/CIF(1 ~ 25/30fps)

Bit Rate Control: CBR/VBR

Bit Rate: H.265 – 12K ~ 8448Kbps, H.264 – 32K ~ 10240Kbps

Day/Night: Auto(ICR) / Color / B/W

BLC Mode: BLC / HLC / WDR(120dB)

White Balance: Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control: Auto/Manual

Noise Reduction: 3D DNR

Motion Detection: Off / On (4 Zone, Rectangle)

Region of Interest: Off / On (4 Zone)

Smart IR: Support

Digital Zoom: 16x

Flip: 0°/90°/180°/270°

Mirror: Off / On

Privacy Masking: Off / On (4 Area, Rectangle)

Audio Compression: G.711a/ G.711Mu/ AAC/ G.726

Ethernet: RJ-45 (10/100Base-T)

Protocol: HTTP,HTTPS,TCP,ARP,RTSP,RTP,RTCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,PPPoE,IPV4/V6,QoS,UPnP,NTP,Bonjour,IEEE 802.1X,Multicast,ICMP,IGMP,TLS

Interoperability: ONVIF Profile S&G, API

Streaming Method: Unicast / Multicast

Max. User Access: 10 Users / 20 Users

Edge Storage: NAS Local PC for instant recording, Micro SD Card 128GB

Web Viewer: IE, Chrome, Firefox, Safari

Management Software: Smart PSS, DSS, DMSS

Smart Phone: IOS, Android

Certifications: CE (EN 60950:2000), UL – UL60950-1, FCC – FCC Part 15 Subpart B

Audio Interface: 1/1 channel In/Out

Alarm: 1 channel In – 5mA 5VDC, 1 channel Out – 300mA 12VDC

Power Supply: DC12V,PoE+ (IEEE 802.3at)(Class 4)

Power Consumption: <15W(-ZAS), <13W(-VFAS)

Operating Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Storage Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection: IP67

Vandal Resistance: IK10(Optional)

Casing: Metal

Dimensions: 244.1mm×79mm×75.9mm (9.61”×3.11”×2.99”)

Net Weight: 0.815kg (1.80lb)

Gross Weight: 1.08kg (2.38lb)

DAHUA
