DAHUA IPC HFW2431S-S-0280B-S2,IP VAIZDO KAMERA 4MP, 2.8MM, IR30

DAHUA IPC HFW2431S-S-0280B-S2,IP VAIZDO KAMERA 4MP, 2.8MM, IR30

159

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Image Sensor: 1/3” 4Megapixel progressive CMOS

Effective Pixels: 2688 (H) × 1520 (V)

ROM: 128 MB

RAM: 128 MB

Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s

Min. Illumination: 0.008 Lux @ F1.6

IR Distance: 30 m (98.43 ft)

IR On/Off Control: Auto/Manual

IR LEDs Number: 2

Pan/Tilt/Rotation Range:

Horizonal: 0°–360°

Vertical: 0°–78°

Rotation: 0°–360°

Lens Type: Fixed

Mount Type: M12

Focal Length: 2.8 mm

Field of View: Horizonal: 102.0°; Vertical: 55.0°; Diagonal: 121.0°

Close Focus Distance: 2.8 mm: 0.9 m (2.95 ft)

General IVS Analytics: intrusion; tripwire

Video Compression: H.265; H.264; H.264B; MJPEG

Smart Codec: Yes

Video Frame Rate:

Main stream:

2688 × 1520 (1 fps-20 fps)

2560 × 1440 (1 fps-25/30 fps)

Sub stream:

704 × 576 (1 fps-25 fps)

704 × 480 (1 fps-30 fps)

Stream Capability: 2 streams

Resolution: 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)

Bit Rate Control: CBR/VBR

Video Bit Rate:

H.264: 32 Kbps–6144 Kbps

H.265: 12 Kbps–6144 Kbps

Day/Night: Auto(ICR)/Color/B/W

BLC: Yes

HLC: Yes

WDR: 120 dB

White Balance: Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control: Auto/Manual

Noise Reduction: 3D DNR

Motion Detection: OFF/ON (4 areas, rectangular)

Region of Interest(RoI): Yes (4 areas)

Smart IR: Yes

Image Rotation: 0°/90°/180°/270° (Supports 90°/270° with 1080p resolution.)

Network: RJ-45 (10/100 Base-T)

Protocol: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability: ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec

User/Host: 20

Edge Storage: Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS

Power Supply: 12V DC/PoE (802.3af)

Power Consumption: < 6.6W

Protection: IP67

Casing: Metal

Dimensions: 100.9 mm × ?109.9 mm (3.97" × ?4.33")

Net Weight: 0.39 kg (0.9 lb)

Gross Weight: 0.56 kg (1.2 lb)

DAHUA
