DAHUA DHI-ASI7213X-T1, VEIDŲ ATPAŽINIMO ĮEIGOS KONTROLERIS, TERMOVIZORIUS

Main Processor: Embedded Processor

Network Protocol: IPv4, RTSP, RTP, TCP, UDP, P2P

OSDP Protocol: Yes

Interoperability: ONVIF; CGI

SDK and API: Support SDK

Display Screen: 7-inch display screen

Screen Type: Capacitive screen

Resolution: 600 (H) × 1024 (V)

Camera: 1/2.8" 2MP CMOS high definition WDR dual camera

WDR: 120 dB

Light Compensation: Auto white light / Auto IR light

Status Indicator: 1 indicator light. Red: Error; Green: Normal; Blue: Working

Voice Prompt: Yes

Casing: Aluminium alloy/tempered glass/PC

Unlock Mode: Card/Remote/Password/Face unlock and unlock through their combinations / Face unlock under temperature monitoring mode

Card Type: IC card

Period List: 128

Holiday Period: 128

First-Card Unlock: Yes

Remote Verification: Yes

Peripheral Card Reader: 1 RS-485, 1 Wiegand

Multiple Authentication: Yes

Real-Time Surveillance: Yes

Web Configuration: Yes

Card Reading Distance: 3 cm

Face Recognition Distance: Face-camera distance: 0.3 m–2.0 m / Human height: 0.9 m–2.4 m

Face Verification Accuracy: 99.5%

Face Recognition Time: 0.2 s

Temperature Monitoring Range: 30°C to 45°C

Temperature Monitoring Error: ? 0.5°C

Temperature Monitoring Distance: 0.3 m–1.8 m

Temperature Monitoring Height

135 cm–185 cm (when temperature monitoring distance is 0.5 m)

120 cm–210 cm (when temperature monitoring distance is 1.2 m)

Capacity

User Capacity: 100, 000

Face Image Capacity: 100, 000

Card Capacity: 100, 000

Password Capacity: 100, 000

Record Capacity: 300, 000 records

RS-485: 1

Wiegand: 1 (input or output)

USB: 1 USB2.0 port

Network: 1 1000Mbps network port / 1 100Mbps network port

Alarm Input: 2 (Switch quantity)

Alarm Output: 2 (Relay)

Alarm Linkage: Yes

Exit Button: 1

Door Status Detection: 1

Lock Control: 1

Anti-passback: Yes

Tamper: Yes

Duress: YES

Door Sensor Timeout: Yes

Intrusion: Yes

Illegal Card Exceeding Threshold: Yes

Power Adapter: Included

Power Supply: 12V 2A DC

Power Consumption: ? 24W

Product Dimensions: 312.5 mm × 129.0 mm × 36.7 mm (12.30" × 5.08" × 1.44")

Operating Temperature

Temperature monitoring mode disabled: –10°C to +55°C (+14°F to +131°F)

Temperature monitoring mode enabled: +15°C to +30°C (+59°F to +86°F)

Operating Humidity: 0%RH–90%RH (non-condensing)

Operating Environment: Indoor

Gross Weight: 2.2 kg (4.85 lb)

Installation: Wall mount

Certifications: CE/FCC
