ASI1201E-D 125KHz autonominis kontroleris
113,74 Į krepšelį

ASI1201E-D 125KHz autonominis kontroleris

113,74

Išankstinis užsakymas

DAUGIAU INFORMACIJOS TEL.: +370 700 30164

Specifikacija
System
Main Processor: 32 Bit
Input/Output Ports
Input: Door sensor x 1, Exit button x 1
Output: Relay x 1 (Door lock,)
Reader: Reader x 1
Card Read
Read Format: 13.56MHz
Read Range: 1cm–2cm (max.)
Response Time: <0.1s
Capacity
Cardholders: 30,000
Events: 60,000
Function
User Management: General, VIP, Guest, Patrol, Black list, Duress
Alarm Function: Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
Period Setting: Support 128 groups of schedule, 128 groups of periods and 128 groups of holiday periods
Interface
To PC: RJ45(10/100M)
To Reader: Wiegand26/34, RS485
General
Ingress Protection: IP66
RTC: Yes
Beep Tone: Buzzer
Keyboard: Sensitive touch keypad with blue backlight
Power Supply: DC 9-15V/100mA
Operating Temperature: -30°C to +55°C
Working Humidity: 10%RH–90%RH (no-condensation)
Dimension(W×D×H): 62.0mm×142.0mm×23.0mm
Weight: 0.5kg
Working Environment: Outdoor
Certificates
CE: Yes
FCC: Yes
DAHUA
